WEJOIN BARRIER GATE CB02VF-E
Shenzhen Weijoin Mechanical&Electrical Co. was founded in 2004. It is the first national high-tech enterprise speciallized in research and development, manufacturing and sales of intelligent access control products in China. As one of the Brand Business Enterprises of Guangdong province, WEJOIN so far is also one of the largest manufacturers in access control and management product. Its main products include automatic barrier gate, tripod turnstile, flap barrier, swing barrier, etc.
The WECB02VF-E barrier gate, which our company manufactured, adopts the latest automatic technology and intelligent design ahead in this field. Meanwhile, our barrier gates have an advanced design, which makes our barrier gates work more safely and conveniently. This barrier gate is suitable for indoor and outdoor parking areas, Parking lots, toll gates, goods yards, railway crossings, commercial premises, apartment block access shopping malls, hospitals, stadiums, business centers, etc.
Technical Data
| Model | WJCB02VF-E |
| Working Temperature | -40℃～+75℃ |
| Voltage | 220V±10%, 110V±10%, 50/60HZ |
| Rated power | 240W |
| Relative humidity | ≤90% |
| Remote control distance | ≥30m |
| Net weight | 60kgs |
| Speed | 0.6S |
| Max boom length | 3 meters |
Quick Detail:
Name: High Speed Barrier Gate ,
Application : Highway toll
Certificate: CE, ISO,
Net Weight:60KG
Voltage: AC220V, AC110V
Rated Power:240W
Speed: 0.6 second
Feature: 100% duty cycle
Model Selection and Differences
| Model | Boom Shape | Max Boom Length | Speed |
| WJCB02VF-E | Straight boom | 3m | 0.6 seconds |
| WJCB02VF-E | Straight boom | 4m | 1 seconds |
Why to choose WEJOIN High Speed Barrier Gate?
1. High Speed Barrier Gate adopts special machine core, swing away boom holder and boom. This barrier gate runs in high speed but stably. The running time is 1 second. It can be used for highway toll.
2. High Speed Barrier Gate uses swing away boom holder. The boom is out of the holder when it is hit, which protects the barrier core and prolong lifetime of the barrier.
3. High Speed Barrier Gate uses the first generation motor. It is stable and has long service life performance, running 3 million times. Its housing is made of galvanized steel with 1.5mm thickness, and painted, so that the barrier can be used in door and outdoor.
4. The barrier core is special and main parts are aluminum alloy casting. The barrier gate will automatically reverse when the boom meets the obstruction. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles. Manual release device can operate the barrier when power failure.
5. WEJOIN has sub-companies to produce and process almost accessories. Besides standard producing, we offer OEM service in the meanwhile.
