Remote control safe lock car parking lock in parking access control Parking Lot Equipment
Specifications:
| Model | WJCS101 |
| Standard Voltage | DC12V |
| Battery Voltage | DC12V, 7Ah |
| Working Temperature | -35℃～+55℃ |
| Vertical Position Height | 340MM |
| Dimension | 357*370*82.5MM |
| Operational Current | 0.4A |
| Remote control distance | ≥30m |
| Net weight | 9kgs |
| Up to Down Time | 4-6S |
| Max Bearing Weight | 5 tons |
| Protection Grade | IP68 |
Applications:
User Scope of products: car owners property management company Property Management Office parking local
production house developers Automobile Dealers auto shop security companies, security shop.
Description:
Remote control parking lock is a kind of device which can be automated lift, the role is to prevent someone else take your
own car parking spaces, let your vehicle and park at your parking lock at any time.
Functions:
Remote control parking lock is a kind of device which can be automated lift, the role is to prevent someone else take your own car parking spaces, let your vehicle and park at your parking lock at any time.
1. Energy-saving; the battery is a best product in China.
Using The United States Champion brand battery, with resistant shock, resistant high temperature, small size, good charge and discharge performance characteristics, theorily can be recharged 5000 times. Most energy-using efficient design patterns to achieve the industry's lowest operating current host 0.4A, starting current 0.6A ~ 0.7A, standby current of 0.6mA, thus ensuring once charging using at least once a year.
2. Safe: the power connection is anti-disconnecting design in case that the user misplaces the battery causing short circuit; battery installation is easy.
3. Durable: the cabinet is made of die-casted Zinc alloy with high quality, and the maximum weight of load-bearing is 5 tons; the cabinet is coated with varnish, being water-proof and anti-rust in harsh weather. The sway arm is made of fiber-reinforced nylon, and it will not deform even after car crushing.
4. Hermetic: the cabinet is tightly closed, and Protection Grade is IP68. It is waterproof and dustproof. It can be used broadly.
5. Auto-repositioning; the external force could not change the sway arm position when it is vertical; when the sway arm is forced to a horizontal position, it will reposition vertically, unless the user uses remote control to put it horizontally.
6. Fixing by Four expansion screws, using internal security design, and the installation location of the host expansion screws inside the shell, only with a key to open the back cover before installation, eliminating the theft risks when parking lock installed outdoors
