Most reliable and efficient vehicle barrier gate for parking lots and toll gate
Parking Barrier Gate Features:
1.- The traffic barrier is widely used for the facilities of parking, traffic, or toll system.
2.- Arms can be chosen from 3 meters to 6 meters.
3.- This type of barrier could match with a direct boom( pole), fold boom, Or fence boom.
4.- Advanced manual release. The clutch key can be used to open the clutch when electricity is cut off.
5.- All the process is soft without any noise and shaking.
6.- This barrier gate has many input terminals for photocell, Airwave switch, loop detector, back-up battery(for DC Motor), toll gate system, and output terminals for a lamp.
7.- Housing color: yellow,red ,blue,orange,white (optional)
8.- Boom arm direction can be chosen from leftward to rightward.
9.- Auto warming up, suitable for a cold environment.
10- Controlling way: wireless or wiring multiple push-button for OPEN, CLOSE, STOP function.
Barrier Gate Model Slection
|
Model |
102-11 |
102-118 |
102-13 |
102-16 |
102-23 |
102-26 |
102-33 |
102-36 |
|
Running time |
1 sec |
1.8 sec |
3 sec |
6 sec |
3 sec |
6 sec |
3 sec |
6 sec |
|
Boom type |
Straight |
90° folding |
180° folding |
|||||
|
Max Boom length |
3m |
4m |
4.5m |
6m |
3m |
5m |
3m |
5m |
|
Boom dimension (WxH)mm |
45*80mm |
45*100mm |
||||||
|
Boom weight |
3.2 kg |
4.5kg |
5.2kg |
6.4 kg |
6.4 kg |
10 kg |
7.9 kg |
13.4 kg |
Working environment and data
1. Mechanism temperature -25℃+85℃
2. Control board temperature -20+85℃
3. Power supply 220V±10% 50/60 Hz
110V±10% 50/60 Hz
1. Rated power 120W
2. Relative humidity ≤90%
3. Remote control ≥30M
4. Net weight 60 Kg
