Advanced Safety Manual Car Parking Barrier Gate With Double Limit Switches
Quick Detail:
Name: High Speed Barrier Gate ,
Application : Highway toll
Certificate: CE, ISO,
Net Weight:60KG
Voltage: AC220V, AC110V
Rated Power:240W
Speed: 2-6 second
Feature: Manual release
Description:
Model Selection and Differences
|
Model |
Boom Shape |
Max Boom Length |
Speed |
|
WJDZE4P |
Straight boom |
6m |
6 seconds |
|
Straight boom |
4.5m |
3 seconds |
|
|
Straight boom |
3m |
2 second |
|
|
90 degree, Articulated boom |
5m |
6 seconds |
|
|
90 degree, Articulated boom |
3m |
3 seconds |
|
|
180 degree, Articulated boom |
5m |
6 seconds |
|
|
180 degree, Articulated boom |
3m |
3 seconds |
|
|
Two-level, fence boom |
4.5m |
6 seconds |
|
|
Three level, fence boom |
3.5m |
6 seconds |
Functions & Features:
1. No spring design, eliminating the need for mechanical leveling, maintenance-free.
2. The boom will not fall off when power off, high safety.
3. Minimal operation, the direction can be exchanged in 30 seconds.
4. Bluetooth control, one-key remote service.
5. The perfect combination of worm gear and gear is reliable.
6. Support external radar, loop detector, infrared photocell anti-smashing function, and built-in DC 12V power output, which can be used for external radar power supply.
7. Support RS485 communication or RS485 off-line connection.
8. DC24V power supply is optional.
Applications:
Fast Barrier Gate adopts special machine core, swing away boom holder and boom. This barrier gate runs in high speed but stably. The running time is 1 second. It can be used for highway toll, parking system, factory gate, and so on.
Specifications
|
Model |
WJDZE4P |
|
Working Temperature |
-40℃～+75℃ |
|
Voltage |
180-265VAC, 50/60HZ |
|
Rated power |
240W |
|
Relative humidity |
≤90% |
|
Remote control distance |
≥30m |
|
Net weight |
60kgs |
|
Speed |
2-6S |
|
Max boom length |
6 meters |
Why to choose WEJOIN High Speed Barrier Gate?
1. High Speed Barrier Gate adopts special machine core, swing away boom holder and boom. This barrier gate runs in high speed but stably. The running time is 1 second. It can be used for highway toll.
2. High Speed Barrier Gate uses swing away boom holder. The boom is out of the holder when it is hit, which protects the barrier core and prolong lifetime of the barrier.
3. High Speed Barrier Gate uses the first generation motor. It is stable and has long service life performance, running 3 million times. Its housing is made of galvanized steel with 1.5mm thickness, and painted, so that the barrier can be used in door and outdoor.
4. The barrier core is special and main parts are aluminum alloy casting. The barrier gate will automatically reverse when the boom meets the obstruction. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles. Manual release device can operate the barrier when power failure.
5. WEJOIN has sub-companies to produce and process almost accessories. Besides standard producing, we offer OEM service in the meanwhile.
