Intelligent flap barrier is a brand-new product of our company. It has features of precise craftsmanship, comprehensive functions and high reliability, which can be applied in high class communities, intelligent buildings, hotels, subway stations and other high level venues and then achieve a more intelligent management and control of pedestrian access. The most typical intelligent application is high speed railway station, subway station, BRT station, scenic ticket system and so on.
Functions & Features
1. With function of self-examine and alarm, it is convenient for maintenance and use.
2. Be able to program running status by the small keyboard in the main board
3. Flap door will stop move when it is being blocked, which prevent pedestrians from being nipped and from hurt.
4. Light and sound alarm is generated when the illegal invasion and the tail followed.
5. Arms are automatically locked until opening signal is received.
6. Arms synchronization (adjustable)
7. Automatically reset function: It will automatically lock if the pedestrian hasn't pass through the channel in the pre-set time after the opening. The passing time is adjustable.(default time is 10sec.)
8. Automatically open the gate when power off and automatically close when power on.
9. Several readers devices are attachable.(IC, ID access control, fingerprint access control, barcode ticket access control, facial identification access control, time attendance machine est.)
10. One direction or bi-direction is optional.
11. It can be directly controlled and managed by remote control.
| Model | WJTY201 | WJTY301 | WJTY311 |
| Material of Housing | 304Stainless Steel | ||
| Material of Flap Door | Organic Glass , Resin, or PVC | ||
| Thickness of Housing | 1.50mm | ||
| Dimension of Housing (LxWxH mm) | 1200*270*1000 | 1450*315*1020 | 1400*305*1020 |
| Net Weight | 70kg | 140kg | 85KG |
| Max Width of Passage | 600 mm | 900 mm | 900 mm |
