Functions & Features
1. Integrated electromechanical design, no need additional control
2. Electronic soft start
3. Reversing on obstacle
4. Anti-bumping and auto backtracking socket
5. Infrared photocell socket
6. Alarm light socket
7. Wires control and remote control
8. Delaying closing
9. Automatic warm-up
Technical Data
|
Model |
MP202 |
|
|
Voltage |
220V±10% |
110V±10% |
|
Current |
2.7A |
5.8A |
|
Absorbed power |
594W |
638W |
|
Working temperature |
-35℃～+85℃ |
|
|
Relative humidity |
≤90% |
|
|
Remote control distance |
≤50M |
|
|
Mode number |
M=4 |
|
|
Gear Speed |
58.5rpm |
70.2rpm |
|
Torque |
35NM |
|
|
Max weight of gate |
1800kg |
|
|
Travel speed |
11m/min |
13.2m/min |
|
Reduction ratio |
23:1 |
|
|
Overload protection temperature |
130℃ |
|
