Optical Turnstiles Flap Barrier Gate with Organic Glass Wing , 600mm Lane Width
Function&Featunre:
1. The turnstile will closed the door when somebody enter the gate illegal, Tailgating or break into negative direction gate.
2. Before received the open signal, the turnstile will lock automatically
3. The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.
4. Automatic Reset Functions: after you swap the card, during the specific time (standard is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 5~20s you can adjust it what time is suit for you).
5. Infrared for Safaty access.
6. The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on.
7. The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles).
8. With Back-up battery.
9. Adjustable access directions
10. Traffic light indicating passenger access
Specifications:
|
Model |
WJTY201 |
|
Stretching-out flap length |
275mm |
|
The max lane width |
600mm |
|
Cabinet material |
Cold rolled steel & aluminum alloy |
|
Material of Flap Door |
Organic glass |
|
Housing of thickness |
1.5mm |
|
Normal Life Span |
3 millions times |
|
Communication Interface |
Standard RS485(distance less than 1200 meters) |
|
Transit speed |
30-40 persons/min |
|
Time for opening or closing |
0.5s |
|
Starting time after power on |
3s |
|
Input interface |
Dry contact signal or +12Vor pulse signal with width more than100ms DC12V |
|
Transit speed |
25~32 persons/min |
|
Working temperature |
-10°C~50°C |
|
Working environment |
Indoor / Outdoor (Shelter) |
|
Relative humidity |
≤95%, no condensation |
