Manual Release Automatic Barrier Gate Boom Gate Remote Car Parking Barrier
Barrier Gate Brief Introduction:
This product uses the latest mold design technology,die-casting manufacturing technology, and no clutch design. So the quality is reliable. And The mechanism uses the gear worm and crank link structure, which makes the boom operate quickly and steadily. And the maintenance will be easy and convenient.
Electronic Barrier Gate Quick Detail:
1. Open the barrier gate by the motor wheel when power is off and automatically reset when power is on.
2.Balanced boom running with a motor transmission of cranks and shafts.
3.Remote control to operate the barrier gate.
4.Auto-reverse when boom meets obstruction (only for barrier using the digital limit device)
5.Infrared photocells interface is available (need to install photocell device).
6.Loop detector interface is available (need to install loop detector).
7. Well-integrated with car parking system equipment, with wire control (must be dry contact signal).
8.Interface for the traffic light,dry contact output (traffic light must be less than 10A)
9. Offering signal of limit status for car parking system (output COM,NC,NO).
10.Auto-closing function(adjustable from 3s to 30s,factory default off this function).
Parking Barrier Gate Motor speed and boom type:
|
Boom type |
Boom Length(M) |
Opening Time(S) |
Height between boom and ground |
|
Straight boom |
6m≥L>4.5M |
6S |
H=0.8M |
|
4.5m≥L>3M |
3S |
||
|
Articulated Boom, 90 Degree |
5m≥L>3M |
6S |
|
|
3m≥L |
3S |
||
|
Articulated Boom, 180 Degree |
5m≥L>3M |
6S |
|
|
3m≥L |
3S |
||
|
Fence boom, two-level |
4.5m≥L |
6S |
H=0.9M |
|
Fence boom, three-level |
4m≥L |
6S |
H=1.5M |
